Sub-Metering Electricity by Zone on Hydroponic Farms
A utility meter at the site gate records what a farm spent last month and says nothing about where the money went. Electricity submetering greenhouse loads by zone turns that single figure into a set: pumps, chillers, lights, fans and the pack house each carry their own kilowatt-hours. Energy monitoring per zone is what makes a load list actionable, because a 12 percent jump in the bill is only a problem once it lands on one feeder. This article sets out which zones deserve a meter, where the current transformers belong, and how to phase the work through year one.
Why One Main Meter Hides Money
A main meter gives two numbers: total energy and the peak demand the tariff is built around. Neither points at a machine. When a monthly bill rises 12 percent, the cause could be a chiller short-cycling, a pump left running a bypass line, a lighting bank still on a winter schedule, or a hotter month. Finding it takes a week with a clamp meter and much guesswork.
Sub-metering splits the site into the circuits a farm controls. Each zone gets a baseline, and a swing above roughly 15 percent becomes a work order instead of a discussion. Start from an energy cost breakdown by system, because the plan is only as good as the categories chosen on day one.
Electricity Submetering Greenhouse Zones: What to Meter
Meter the loads that are large, variable and controllable, and leave the rest until a season of data shows where the noise is. Every kilowatt-hour has to land in exactly one zone, so meter the remainder or subtract zones from the main meter and keep the gap under about 8 percent. Zones follow the switchboard rather than the site map.
| Zone | Share of site kWh | Load character | Priority | Question the data answers |
|---|---|---|---|---|
| Irrigation and circulation pumps | 12 to 25% | Intermittent, high inrush | 1 | Is pumping running longer than the crop needs? |
| Chillers and heat pumps | 15 to 30% | Long runs, seasonal | 1 | Is dehumidification fighting the heating? |
| Grow lights | 25 to 45% | Steady, schedulable | 1 | What does one extra light hour cost? |
| Ventilation, HAF and HVAC | 5 to 15% | Continuous, low per unit | 2 | Are fans running with the house closed? |
| Pack house and cold rooms | 5 to 12% | Business hours, spiky | 2 | What does a packed case cost to chill? |
| Office and workshop | 2 to 6% | Small, steady | 3 | Is the base load drifting upward? |
Meter Types and Where the CTs Go
Three hardware routes cover most farms: a panel kilowatt-hour meter with a pulse output, a current transformer power meter with a digital bus, and a multi-circuit branch monitor reading every way in one board.
| Meter type | Installation | Accuracy | Best application | Watch out for |
|---|---|---|---|---|
| Panel kWh meter, pulse output | DIN rail, direct to about 100 A | Class 1 | One sub-board, one zone | Pulses need a battery-backed logger |
| Split-core CT power meter | Clip on, no conductor break | 1% typical | Retrofit on live boards | Lead length, orientation, clip seating |
| Solid-core CT power meter | Feeder must be broken | 0.5% typical | New build, large feeders | Needs an outage, licensed electrician |
Current transformer placement causes more bad data than meter selection. Clamp the phase conductors of one feeder only, since a multicore cable carrying two circuits reads the difference and phase plus neutral reads near zero. Keep every CT facing the same way and label each with board and way. Size the ratio at 1.25 to 1.5 times expected continuous current, and never open-circuit a CT secondary while the circuit is energised.
Fit meters at the board feeding the zone rather than at the equipment. Where a variable frequency drive feeds a pump, meter the line side of the drive,
Interval Logs, Dashboards and What to Record
A meter read once a month by eye delivers a fraction of its value. Interval logging turns the same hardware into a fault detector.
- Interval: 15 minutes matches the billing window; drop to 1 minute only for short pump studies.
- Channels: kilowatt-hours imported, average and peak kilowatts, phase voltages and power factor. Power factor under about 0.9 on a motor load points at an oversized motor.
- Storage: log inside the meter with a month of buffer so a network outage leaves no gap, and keep 13 months.
Log at the billing interval, and log it inside the meter rather than only in the gateway.
On most sites the first month of interval data finds something worth fixing before any analysis starts: a chiller restarting every six minutes, a pump that never shuts off, a lighting schedule running at noon. That discovery is the payback, and it is lost if the logger drops data when the network stumbles.
kWh per kg and kWh per m2-Week
Two normalisations make zone data comparable. Kilowatt-hours per kilogram harvested connects energy to the product and is the number to watch when the crop or schedule changes. Kilowatt-hours per square meter per week benchmarks the building.
Benchmark ranges worth putting on the dashboard: temperate NFT lettuce 0.8 to 2.5 kWh per kilogram, or 1 to 4 kWh per m² per week; heated tomato with supplemental light 3 to 8 kWh per kilogram; a fully lit plant factory 8 to 15 kWh per kilogram and 15 to 30 kWh per m² per week.
Worked example: a 2,000 m² lettuce site harvesting 60,000 kg a year on 96,000 kWh runs at 1.6 kWh per kilogram. If the pump zone logs 18,000 kWh, pumping is 0.30 kWh per kilogram, and a 20 percent rise without a scheduling change usually means blocked filters or a leaking bypass. Tracked monthly, that drift shows up two months before it reaches the bill.
Set one target per zone rather than one for the site, and keep that number beside yield and labor on one scorecard.
Time-of-Use Tariffs and Demand Charges
Most commercial tariffs have two parts. Energy is billed per kilowatt-hour at rates that vary by time of day, and capacity is billed on the highest average demand in any 15 or 30 minute window of the month. Zone data makes both controllable, because it shows which zone set the peak.
Time-of-use rates reward shifting: pre-cool cold rooms before the peak window, run the main irrigation fill outside it, and move lighting blocks off peak where the crop allows. Shifting 20 to 30 percent of a schedulable load commonly trims 5 to 12 percent off the energy line. Demand charges respond to sequencing: two compressors starting together can set the month in a quarter of an hour, so stagger large motor starts by 3 to 8 minutes.
Where storage is on the table, the interval data supplies the load shape a battery sizing study needs, and the case for load shifting under peak tariffs stands or falls on it. Cutting the site peak by 10 to 20 percent through sequencing is realistic in year one.
A First-Year Metering Plan on a Small Budget
A full rollout is rarely the right first move. Four phases spread the cost: main meter plus three or four zone feeders in months 0 to 1; pump station and pack house sub-boards in months 2 to 3; a gateway with a weekly report in months 4 to 6; a tariff review in months 7 to 12.
Hardware for an electricity submetering greenhouse setup at four to six split-core points typically lands in the low four figures in US dollars, with installation labor the larger and more variable part. Payback is commonly six to eighteen months, from a fault found early, a demand peak avoided and a better tariff. Thresholds that turn data into action are set out in the alarm threshold and escalation guide.
Frequently Asked Questions
How many sub-meters does a one hectare greenhouse need?
A: Four to six points to start: pumps, chillers or heating, lighting, ventilation and a remainder. Add more after a season once the data shows which block moves.
Can current transformers be fitted without shutting down?
A: Split-core and Rogowski types clamp on without breaking the conductor, although a licensed electrician still has to open the board. Solid-core CTs need an outage.
What accuracy class is needed for cost allocation?
A: Class 1 is enough for an internal cost split and fault finding. Class 0.5S earns its premium only where the reading supports tenant billing.
How often should interval data be logged?
A: Every 15 minutes to match the billing interval. Use one-minute logging only for a focused study lasting a few weeks.
Does installing meters reduce the bill by itself?
A: No. The meter locates the waste; the saving comes from what is changed afterwards, typically 5 to 15 percent of the electricity line.
Get a Zone Metering Point List for Your Farm
Electricity submetering greenhouse loads pays back in the order the zones are chosen, not in the number of meters bought. Energy monitoring per zone turns a monthly argument about the bill into a short list of circuits with numbers attached, and the first phase is small enough to fund from an operating budget. Send the single-line diagram, board schedules and the last twelve months of bills.
To Send your single-line diagram and we will mark the metering points that pay back first., include transformer capacity and the largest motor ratings, because those set the CT sizes.
