FIELD APPLICATIONS & SYSTEM LAYOUTS

Commercial Hydroponic Projects.
See Them in Use.

Explore NFT growing systems, greenhouse applications and layout references for commercial hydroponic projects. Use these examples to help plan your crops, growing space and equipment requirements.

A CLOSER LOOK

From channels to crops.

02 / FIELD APPLICATION

Growing channels, crop rows and greenhouse access.

FIELD APPLICATION

NFT Growing Systems
in a Greenhouse

A closer look at horizontal growing channels in use. The photograph shows the channel arrangement, crop rows and working space inside the greenhouse.

SETTING
Greenhouse
ARRANGEMENT
Horizontal channel rows
APPLICATION
Leafy vegetable growing
VISIBLE DETAILS
Channels, crops & aisles
DIFFERENT SPACES. DIFFERENT ARRANGEMENTS.

Explore NFT system layouts.

Look at how channels are arranged, then consider the light, access and space available at your own site.

01
SYSTEM LAYOUT REFERENCE

Horizontal NFT Layout

Channels arranged in horizontal rows, with a clear view of the growing area and access between planting sections.

Horizontal rows
Greenhouse layout

The photograph shows horizontal channels, their supports and connected feed tubes before planting.

Row spacing and aisle widths should be reviewed against the site dimensions and the way crops will be managed.

02
SYSTEM LAYOUT REFERENCE

A-Frame NFT Layout

An A-type arrangement for considering planting space, channel positioning and access within a greenhouse.

A-type arrangement
Light orientation

The photograph shows red and green leafy crops arranged on an A-frame rack with channels at different heights.

Rack orientation, light reaching the lower channels and access to each row should be considered when planning the layout.

03
SYSTEM LAYOUT REFERENCE

Channel & Support Setup

A view of the channels, metal supports and connections before crops are added to the growing rows.

Channel installation
Support structure

The photograph shows installed channels, planting holes and their supporting structure inside a greenhouse.

Channel spacing, feed connections and access should be reviewed alongside the site layout and maintenance requirements.

Layout references illustrate system arrangements. The final design depends on your crop, site and operating requirements.

BEFORE CHOOSING A LAYOUT

What should your project plan include?

A useful starting point is your growing space and the way you intend to use it. Bring these four details into the conversation.

A site sketch or a few photographs can help explain your available space. You can also explore our hydroponic growing equipment to review available product options before discussing your project.

01

Tell us what you plan to grow and whether you already have a preferred growing method or system layout.

02

Share the project location, usable dimensions and whether the growing area is a greenhouse or an indoor space.

03

Describe the available light and the access you need for planting, crop care, cleaning and harvesting.

04

Let us know if you need channels and supports, or would like to discuss the requirements for additional equipment.

YOUR NEXT GROWING PROJECT

Planning a similar growing setup?

Share your location, crop and available growing area. We can discuss the equipment requirements for your project.

Request a Project Quote

Tell us about your requirements. Our team will review your inquiry and contact you about the next steps.
